Length presetting disc

Stop disc for setting and adapting the clamping length

Application

1. press and mount the disc from the side of the shank
Cutter protrusion = desired cutter length + 2 mm (disc thickness)



2. shrink the milling cutter and insert it into the holder



3. remove the length presetting disc once the shrinking process is complete.
Use circlip pliers to insert and remove the length adjustment disc when
the length adjustment disc if it is difficult to remove from the drill shank.
