ThermoGrip® ISG 1200
The inexpensive compact entry-level shrinking machine
Field of application Application
Application: Entry-level shrinking device Ø 3 mm - 32 mm
Features
- Simple input of shrink parameters by scanning barcodes
- Energy-saving induction technology ensures long tool life
- Precise centering of the tool
- Low space requirement and mobile use
- Maximum holding force and enduring strength even in oily environments
- For over 20 years, ThermoGrip® shrink units have stood for innovative premium devices in shrink technology
- Clamping range Ø 3 - 32 mm for all shrink fit chucks T, TSF, TB (HSS Ø 10 - 20 mm / HM Ø 3 - 32 mm)
- Integrated air cooling (cooling adapter optionally available)
- Maximum tool length from taper zero line: 450 mm @ HSK-A63
- Cooling length: 200 mm
The entry-level ThermoGrip® ISG 1200 - 20% less energy consumption with comparable performance
Clamp your tools safely and quickly - for more efficiency in your production
- Insert tool holder
- Scan barcode
- Insert ferrite disk
- Place coil on tool holder
- Press the start button
- Insert or remove tool
